Single bag Middle-seal Corner-cutting Wrapping Machine---ZF02L
UPH 800 for 100-200mm, 750 for 200-250mm. L+H≤380mm, W+H≤380mm. Seamless conveyor connection. Request a quote!
- Overview
- Parameter
- Recommended Products
Core Product Advantages:
1.Conveyor Integration: Designed for direct connection to upstream/downstream conveyors, enabling fully automated production lines.
2.Compact Footprint: Ideal for small boxes (L100-250mm) with speed up to 800 pcs/hr for 100-200mm boxes.
3.Consistent Output: Maintains >98% yield with precise film sealing and cutting.
4.User-Friendly Controls: PLC with HMI allows quick size changes and parameter adjustments.
5.Low Maintenance: Robust construction with easily accessible components minimizes downtime.
Application Scenarios：
Service Guarantee:
1.1 year full machine warranty
2.Free on-site installation and training
3.24/7 remote technical support
4.Spare parts availability
Parameter
| Single bag Middle-seal Corner-cutting Wrapping Machine---ZF02L |
||||||
| Item number | Product Compatible Sizes/mm | |||||
| L (Length) | W(Width) | H (Height) | Sealing Cutter Length | Bag Making Cutter Length | Corner Cutter Length | |
| 1 | 90~250 | 55~250 | 25~160 | 400 | 480 | 170 |
Notes:1.Within the equipment's compatibility range, the product box's external dimensions must meet the following requirements:
Box L + Box H ≤ 380mm, Box W + Box H ≤ 380mm
2.The box inlet direction is shown in the diagram.
UPH
≥800Pcs (Product box length 100~200mm)
≥750Pcs (Product box length 200~250mm)
Note: The product box must be free of burrs and sharp corners, have a regular shape, and the membrane material must be cross-linked POF.
